KS-P12 Backlit Access Control Keypad 3×4KS-P12 背光门禁键盘 3×4
Model型号: KS-P12
12-key backlit zinc-alloy keypad with IP66 rating for door entry, intercoms and outdoor access control systems.12 键背光锌合金键盘，IP66 防护，适用于门禁、对讲与户外出入控制系统。
Key Features核心特性
- Blue LED backlight
- IP66 outdoor rated
- Wiegand 26/34 or matrix output
- Chrome-plated zinc alloy
- 蓝色 LED 背光
- IP66 户外等级
- Wiegand 26/34 或矩阵输出
- 镀铬锌合金
- Factory direct源头工厂
- OEM / ODM available支持 OEM / ODM
- Reply within 24h24 小时内回复
KS-P12 is built for doors, gates and elevators exposed to rain, sun and frequent use. The backlight makes codes easy to enter at night.
Outdoor Access Control
- Conformal-coated PCB against condensation
- Anti-tamper screws
- Matching 4×4 and 3×5 versions available
Common in residential buildings, data centers, warehouses and parking barriers.
KS-P12 专为暴露在雨水、阳光下且使用频繁的门、闸机和电梯设计，背光让夜间输入密码更方便。
户外门禁
- PCB 三防涂覆，防凝露
- 防拆螺丝
- 另有 4×4 和 3×5 版本
常用于住宅楼、数据中心、仓库与停车道闸。
| Keys按键数 | 12 keys (0-9, *, #)12 键（0-9、*、#） |
|---|---|
| Interface接口 | Wiegand 26/34, 3×4 matrix, USB optionalWiegand 26/34、3×4 矩阵，可选 USB |
| Protection防护等级 | IP66IP66 |
| Material材质 | Chrome-plated zinc alloy镀铬锌合金 |
| Key Travel按键行程 | 0.5 mm0.5 mm |
| Actuation Force触发力 | 300 gf300 gf |
| Backlight背光 | Blue LEDBlue LED |
| Operating Voltage工作电压 | 12 V DC12 V DC |
| Lifetime按键寿命 | > 1 million operations> 100 万次 |
| Operating Temperature工作温度 | -30°C to +75°C-30°C to +75°C |
| Dimensions外形尺寸 | 76 × 102 × 20 mm76 × 102 × 20 mm |
All parameters can be customised for your project. Contact us for full drawings.以上参数均可按项目需求定制，如需完整图纸请联系我们。
