Custom Metal Keypad with Your Layout & Legends按您的布局与字符定制金属键盘
1 / 4
Custom Metal Keypad with Your Layout & Legends按您的布局与字符定制金属键盘
Model型号: OEM-MK
Stainless steel keypads in custom matrices (1×4 up to 6×8) with laser-etched or color-filled legends, backlight and any interface.定制矩阵（1×4 至 6×8）不锈钢键盘，激光雕刻或填色字符，可选背光及任意接口。
Key Features核心特性
- Custom matrix from 1×4 to 6×8
- Laser-etched, color-filled or printed legends
- Optional LED backlight
- USB / RS232 / matrix / I²C
- 定制矩阵 1×4 至 6×8
- 激光雕刻、填色或印刷字符
- 可选 LED 背光
- USB / RS232 / 矩阵 / I²C
- Factory direct源头工厂
- OEM / ODM available支持 OEM / ODM
- Reply within 24h24 小时内回复
Tell us how many keys you need and what each one should say. We supply 3D files for approval within 3 working days and samples in 2-3 weeks.
Customization Process
- 316L option for marine and chemical environments
- Key caps in red, green, yellow for function coding
- Matching bezel and gasket supplied
Used on elevators, fuel dispensers, industrial controllers and security consoles.
告诉我们您需要多少按键以及每个按键的字符，我们会在 3 个工作日内提供 3D 文件确认，2-3 周交付样品。
定制流程
- 可选 316L，适用于海洋和化工环境
- 红、绿、黄键帽用于功能区分
- 配套面框和密封圈
应用于电梯、加油机、工业控制器和安防控制台。
| Keys按键数 | 4 - 48 keys4 - 48 键 |
|---|---|
| Interface接口 | USB / RS232 / matrix / I²CUSB / RS232 / 矩阵 / I²C |
| Protection防护等级 | IP65 - IP67IP65 - IP67 |
| Material材质 | 304 / 316L stainless steel or zinc alloy304 / 316L 不锈钢或锌合金 |
| Key Travel按键行程 | 0.45 mm0.45 mm |
| Actuation Force触发力 | 250 - 450 gf250 - 450 gf |
| Lifetime按键寿命 | > 2 million operations> 200 万次 |
| Operating Temperature工作温度 | -30°C to +70°C-30°C to +70°C |
| Surface Treatment表面处理 | Brushed, bead-blasted, black PVD拉丝、喷砂、黑色 PVD |
| MOQ起订量 | 100 pcs100 pcs |
All parameters can be customised for your project. Contact us for full drawings.以上参数均可按项目需求定制，如需完整图纸请联系我们。
- Custom Metal Keypad with Your Layout & Legends Datasheet规格书 PDF · 3.2 KB Download下载
- Industrial Keyboard Product Catalog 20262026 工业键盘产品目录 PDF · 10 KB Download下载
- Membrane Switch Design Guide薄膜开关设计指南 PDF · 2 KB Download下载
- IP Rating Selection Guide for Keyboards键盘防护等级选型指南 PDF · 2.2 KB Download下载
Engineered for Demanding Environments为严苛环境而生
Sealed, rugged and reliable for years of daily operation.防水、防尘、防暴力，长期稳定运行。
Request a Quote获取报价
Tell us your quantity, interface and customisation needs. Our engineers will reply within 24 hours.告诉我们您的数量、接口和定制需求，工程师将在 24 小时内回复。
- Free sample evaluation免费样品评估
- Custom logo, layout and interface支持 Logo / 布局 / 接口定制
- CE / FCC / RoHS certifiedCE / FCC / RoHS 认证
